Automatic Wine Corking Machine
video

Automatic Wine Corking Machine

This machine has functions of feeding and pressing wooden corks automatically. Working speed can reach 20-60 bottles/min. The machine can be customized to suit for your production demands.
Send Inquiry
Product Introduction

Automatic Wine Corking Machine



-Description

This corking machine can be used for capping wine bottles, whiskey bottles, cider bottles. It can be used in wine, beverage industries. The machine can be used together with wine filling and labeling machine.



-Feature

[Pressing Head] The cork pressing head is with powerful cylinder, which makes it press caps well. The working head of pressing head can be adjusted according to container size.

[Feeding Structure] The machine can feed wooden corks before capping automatically, which greatly improve efficiency. The feeding guide rail can be customized according to your cork size.

[PLC control] This automatic wine corking machine adopts PLC control panel, which makes it more convenient to debug and control machine. The panel's language can be customized as your need.

[Conveying System] Designed with chain conveyor belt, this machine can convey containers steadily. The conveying speed of conveyor is adjustable.



Application



-About Customization

[For Different Wooden Corks] ZONESUN can customize this capping machine according to your cork size. Please contact us if you need.

[Access to production line] ZONESUN has wine filling machine and labeling machine which can work with this wine corking machine to promote production. And we can also customize the capping machine to make it adapt to your exiting filling line.



Hot Tags: automatic wine corking machine, China automatic wine corking machine manufacturers, suppliers, factory, wine capping machine, wine bottle capper machine, Snap Capping Machine, Press Capping Machine, gum capping machine, wine bottle capping machine

Parameter

Machine Model

ZS-XG16D1

Working Voltage

AC220V/110V 50-60HZ

Bottle Height

30-300mm

Bottle Caps Diameter

18-70mm

Bottle Diameter

30-100mm

Working Speed

20-60 bottles/minute(depending on bottle and caps)

Working Pressure

0.4-0.6 MPa

Size Of Air Compressor Connector

OD 8mm

Conveyor Length

115mm(W)*1020mm(L)

Machine Size

About 680*680*1730mm

Machine Weight

About 112.5kg

Package Size

About 770*1650*1970mm

Package Weight

About 180kg



Diagram



Details



Detail-1

Detail-2

Real Shot-1

Real Shot-2





-Why Choose ZONESUN Corking Machine

The automatic wine corking machine is a capping device designed to make the process of corking wine bottles easier and faster. With this technology, wine manufacturers can now improve their production volumes, reduce costs, and increase their overall efficiency.

One of the remarkable features of ZONESUN automatic wine corking machine is its customizability. This device can be designed to fit the diverse needs of individual wineries, depending on the nature of their production process. For instance, it can be customized to work with different cork sizes, shapes, and densities, thus giving the manufacturers more control over their production process.

Another advantage of this machine is easy to operate and requires minimal maintenance, thus reducing the overall production costs. With its user-friendly interface and precision engineering, it can consistently deliver high-quality results, ensuring that winemakers maintain their brand reputation and customer satisfaction.
