Water Bottle Filling and Capping Machine
video

Water Bottle Filling and Capping Machine

This machine has functions of feeding plastic bottles, rinsing bottles, filling liquid, feeding bottle covers and capping bottles automatically. Packaging speed can reach 2500-3000 BPH. The water bottle filling and capping machine can be customized according to your production need.
Send Inquiry
Product Introduction

Water Bottle Filling And Capping Machine



-Description

This machine can be applied for packing liquid like mineral water, juice without pulp, oil. It integrates functions of feeding, filling and capping, which can greatly save production space. The mineral water bottle packing machine can be used in drink industries.



-Feature

[Filling System] The parts in contact with filling materials are made of 304 stainless steel, which can ensure production quality. The quantity of filling nozzles can be customized as your need.

[Feeding System] This machine can feed water bottles automatically, which saves labor cost. The feeding structure can be customized to suit for your bottles.

[PLC Control] The water bottle filling and capping machine applies PLC control panel, enabling it to debug and control machine easily. The panel's language can be customized as your need.

[Access To Production Line] This mineral water bottle packing machine can work with sleeve labeling machine and other water treatment equipment to complete automated production. Please contact us if you need.



Application



-About Customization

This water bottle filling and capping machine can be customized according to your production demands. We'll appreciate it if you can send your detailed production information to us, such as filling material, bottle size, bottle cap size and filling volume.



Hot Tags: water bottle filling and capping machine, China water bottle filling and capping machine manufacturers, suppliers, factory, test tube filler, spout pouch packing machine, liquid detergent pouch packing machine, Monoblock Filling Machine, spout pouch packaging machine, Water Bottle Filling and Capping Machine

Parameter

Machine Model

ZS-AFC883

Machine Power

1.5KW

Pressure of Supplying Water

>0.06MPa ≤0.2Mpa

Working Capacity

2500-3000 bottles/hour(based on 500ml)

Applicable Bottle

Plastic PET Bottles

Applicable Bottle Size

50mm≤φ≤115mm 160mm≤H≤320mm

Machine Size

About 2000*1400*2200(L*W*H)

Machine Weight

About 2000kg



Diagram of Mineral Water Bottle Packing Machine



Details



Details-1

Details-2

Real Shot
