Tea Bag Filling and Sealing Machine
-Description
Designed for tea bags, this packaging machine can pack 30-40 bags/min. The machine can also be customized for triangle bag packing.
-Feature
[Quantitative Filling] Designed with measuring cups, the filling machine can fill tea leaves accurately. The measuring cups can be changed or customized to suit for your need.
[Sealing System] The tea bag packing machine adopts the way of heat sealing, which can seal films firmly. The sealing time and temperature can be set on panel easily.
[PLC Control] This tea bag filling and sealing machine is designed with PLC operation panel, which can help you to set or adjust working parameters like waiting time easily. The language of panel can be customized as your need.
[Smart Control] Adopting a smart sensor to detect films, the machine can output and cut films accurately. Its sensitivity can be adjusted by knob easily.
[Reasonable Design] The parts in contact with tea leaves are made of stainless steel, which can ensure your production quality. And it can run stably during production.
-About Customization
[For Unique Packing Demands] ZONESUN can offer customized solution for packing tea bags, meeting your unique demands. Please send your detailed information to us, for example, tea bag size, packing type and capacity demands.
Hot Tags: tea bag filling and sealing machine, China tea bag filling and sealing machine manufacturers, suppliers, factory, vertical form fill seal machine manufacturers, small tea bag packing machine, sachet water packing machine, ampoule packaging machine, Water Pouch Packing Machine, ampoule filler sealer
|
Machine Model |
ZS-FS622 |
|
Voltage |
220V/50Hz |
|
Power |
3.7kW |
|
Measuring Method |
Cup Measuring |
|
Packaging Speed |
About 30-40 bags/min(depending on bag size and filling materials) |
|
Filling Range |
3-10g |
|
Inner Bag Size |
(L)50-70mm*(W)45-80mm |
|
Outer Bag Size |
(L)80-120mm*(W)75-95mm |
|
Sealing Way |
3 Sides Sealing |
|
Air Consumption |
≥0.4m³/min |
|
Machine Size |
About 1500*650*2250mm(L*W*H) |
|
Machine Weight |
About 550kg |
|
Machine Configuration |
||
|
Machine Component |
Brand |
Origin |
|
Servo Main Motor |
Leadshine |
Shenzhen, China |
|
Control Panel |
FLEXEM |
Shanghai, China |
|
Motor(for feeding film) |
Leadshine |
Shenzhen, China |
|
Solid State Relay |
MGR |
Zhejiang, China |
|
Intermediate Relay |
APT |
Shanghai, China |
|
Air Switch |
CHNT |
Zhejiang, China |
Details
With PLC control panel, you can set or adjust working parameters easily. The language of panel can be customized as needed.
With stainless steel hopper, it can ensure production quality. It adopts the way of cup measuring, which can fill materials quantitatively.
With film holder, it can feed films automatically, saving labor cost and improving efficiency.
With the way of heat sealing, it can seal bags firmly. The sealing temperature can be set on panel easily.
-Reasons why choosing ZONESUN Tea Bag Filling Sealing Machine
The machine is a revolutionary piece of equipment that brings immense benefits to production processes. This machine is designed to increase production efficiency and productivity in tea production factories.
Firstly, by automating the filling and sealing process, the tea bag filling and sealing machine frees up human resources and allows companies to increase their output without hiring additional labor. With the usage of this technology, tea companies can meet fulfilling orders and meet the demand of their customers with ease.
Secondly, the machine is capable of filling and sealing large quantities of tea bags in a matter of minutes. This makes it possible for tea manufacturing companies to keep up with the demands of their customers and quickly produce tea bags to meet the needs of the market.
Moreover, this tea bag filling and sealing machine is incredibly accurate and can fill each tea bag with the exact amount of tea required, reducing waste of tea leaves and lowering the overall cost of production. By optimizing the production process, tea companies can reduce the amount of waste and also enjoy higher profit margins.
