Foil-lined Cream Jar Filling Capping Machine
Machine Introduction:
This foil-lined cream jar filling capping machine can realize automatic material filling, foil feeding, heat sealing, cap loading and capping. It is made in monoblock design, which is space-saving and can accommodate different sizes of containers. The machine can also work with rinsing machine and labeling machine to speed up production.
Hot Tags: foil-lined cream jar filling capping machine, China foil-lined cream jar filling capping machine manufacturers, suppliers, factory
|
Machine model |
ZS-AFC28B |
|
Power supply |
110/220V 50-60HZ 4.7kW |
|
Working capacity |
25-30pcs/min |
|
Recommend filling range |
50-75ml(Customizable) |
|
Filling pump |
Magnetic Pump |
|
Max Flow Rate |
30L/min*2 |
|
Bottle diameter |
62mm(Customizable) |
|
Bottle height |
41mm(Customizable) |
|
Bottle mouth diameter |
44mm(Customizable) |
|
Filling accuracy |
±2% |
|
Machine size |
About 3000*1800*2250mm |
Details
PLC Operation Panel
With PLC panel, it provides quick on-screen adjustments of parameters. Multiple languages can be customized as your need.
Anti-dripping Filling Heads
Anti-dripping design can ensure production cleanliness. The filling height can be adjusted to suit for different containers.
SUS316 Magnetic Pumps
Max flow rate can reach 30L/min. The servo-driven pumps ensure high filling accuracy of viscous products.
Foil Sealing Components
Can feed and seal foil lids to cosmetic jars automatically. The sealing temperature is adjustable.
Double Capping Heads
The capping heads are controlled by servo motor. Capping torque can be adjusted according to production needs.
Cap Feeding Machine
Can transport jar caps to guide rail automatically. This can help to save labor.
